Machine Model | ECFP-F205000 |
Build Volume (X x Y x Z) (height incl. build plate) | 2050 x 2050 x 1100 mm (80.71x80.71x43.31 in) |
Optical System | Fiber Laser 36 / 49 / 64 x 500 W (700 W and 1000 W are optional) |
Spot Size | 70 - 120 μm |
Max Scan Speed | 8 m/s |
Layer Thickness | 20 - 120 μm |
Theoretical Printspeed | Up to 1080 cm³/h |
Material | Titanium Alloy, Aluminum Alloy, Nickel Alloy, Maraging Steel, Stainless Steel, Cobalt Chrome, Copper Alloy, etc. |
Power Supply | 380 V, 50 / 60 Hz, 117 kW |
Gas Supply | Ar / N2 |
Oxygen Content | ≤ 100 ppm |
Dimension (W x D x H) | 12685 x 7185 x 6530 mm |
Weight | 145000 kg |
Software | EPControl, EPHatch |
Input Data Format | STL or other Convertible File |
